Telescopic rod guide Aluminium Oxide

Zebco®
Telescopic rod guide Aluminium Oxide
  • main_10986
  • gallery_5293_10339

Code: VAA0001

Quality guides for telescopic rods with a total range from 2.5 mm to 26 mm diameter tube. Guide is made of metal, ring is made ofaluminum oxide and is seated directly in a metal frame. To illustrate - the largest guide of tube 26 mm weighs 13 g.   The dim... Full description

Manufacturer: Zebco® Need help? +420604994440

Price: 1,350 $

Original price: 1,800 $

You will save: 0,450 $ (-25%)

+
Add to cart

Similar products

Specifications

Frame material metal
Ring Material aluminium oxide

Product description

Quality guides for telescopic rods with a total range from 2.5 mm to 26 mm diameter tube. Guide is made of metal, ring is made ofaluminum oxide and is seated directly in a metal frame. To illustrate - the largest guide of tube 26 mm weighs 13 g.



The dimensions of guides as shown :

Tube diameter

Dimension A

Dimension B

Dimension C

2,5 mm

5,1 mm

15,9 mm

2,5 mm

2,8 mm

5,1 mm

16,9 mm

2,8 mm

3,0 mm

5,1 mm

16,9 mm

3,0 mm

3,2 mm

5,1 mm

17,5 mm

3,2 mm

3,5 mm

5,1 mm

18,5 mm

3,5 mm

4,0 mm

6,9 mm

20,6 mm

4,0 mm

4,5 mm

6,9 mm

21,5 mm

4,5 mm

5,0 mm

8,2 mm

25,5 mm

5,0 mm

5,5 mm

8,2 mm

26,5 mm

5,5 mm

6,0 mm

8,2 mm

27,1 mm

6,0 mm

6,5 mm

8,2 mm

27,5 mm

6,5 mm

7,0 mm

8,2 mm

27,5 mm

7,0 mm

7,5 mm

8,2 mm

28,5 mm

7,5 mm

8,0 mm

10,8 mm

36,1 mm

8,0 mm

8,5 mm

10,8 mm

36,1 mm

8,5 mm

9,0 mm

10,8 mm

37,5 mm

9,0 mm

9,5 mm

10,8 mm

38,0 mm

9,5 mm

10,0 mm

10,8 mm

38,0 mm

10,0 mm

10,5 mm

10,8 mm

38,0 mm

10,5 mm

11,0 mm

10,8 mm

38,0 mm

11,0 mm

11,5 mm

10,8 mm

38,0 mm

11,5 mm

12,0 mm

13,9 mm

44,5 mm

12,0 mm

12,5 mm

13,9 mm

44,5 mm

12,5 mm

13,0 mm

13,9 mm

45,1 mm

13,0 mm

13,5 mm

13,9 mm

46,0 mm

13,5 mm

14,0 mm

13,9 mm

47,0 mm

14,0 mm

14,5 mm

13,9 mm

47,0 mm

14,5 mm

15,0 mm

18,1 mm

55,5 mm

15,0 mm

15,5 mm

18,1 mm

55,5 mm

15,5 mm

16,0 mm

18,1 mm

56,5 mm

16,0 mm

16,5 mm

18,1 mm

56,5 mm

16,5 mm

17,0 mm

18,1 mm

57,0 mm

17,0 mm

17,5 mm

18,1 mm

57,0 mm

17,5 mm

18,0 mm

23,2 mm

61,2 mm

18,0 mm

18,5 mm

23,2 mm

62,5 mm

18,5 mm

19,0 mm

23,2 mm

67,5 mm

19,0 mm

19,5 mm

23,2 mm

69,2 mm

19,5 mm

20,0 mm

23,2 mm

69,2 mm

20,0 mm

21,0 mm

23,2 mm

69,2 mm

21,0 mm

22,0 mm

23,2 mm

72,2 mm

22,0 mm

23,0 mm

23,2 mm

72,2 mm

23,0 mm

24,0 mm

23,2 mm

73,8 mm

24,0 mm

25,0 mm

23,2 mm

74,1 mm

25,0 mm

26,0 mm

23,2 mm

75,2 mm

26,0 mm
